Tripp Lite, UPS, OmniSmart LCD 1500VA, 810W, Tower AVR, 10 x 5-15R Outlets, USB Port, RJ11, RJ45

The OMNI1500LCDT Line-Interactive Tower UPS System offers voltage regulation, surge suppression and long-lasting battery support for personal computers, network workstations, home entertainment systems and media centers. Internal UPS circuits support entry-level PCs or individual VCR/DVR components during power failures. Prevents data loss, viewing interruptions, lost recordings and loss of component programming. Automatic Voltage Regulation (AVR) circuits continuously regulate brownouts and overvoltages from 92V to 150V back to usable levels, all while maintaining a full battery charge. Offers complete power protection in an attractive all-black cabinet design. Includes 10 built-in outlets, five with full battery backup and surge suppression for vital system components and another five with surge suppression only for accessories not requiring battery support. Built-in USB port and included cable enables optional unattended system shutdown without data loss in case of extended power failure. PowerAlert(R) software is available via free download. HID-compliant USB interface also enables integration with built-in power management and auto shutdown features of Windows and macOS. Built-in surge dataline surge suppression jacks protect equipment with single-line dialup/DSL or network Ethernet connection. Built-in audible alarm and large LCD front panel display offers easy to read icon-based status indicators and detailed numeric data regarding input voltage, output voltage, frequency, load percentage, load watts, battery voltage and runtime in minutes. 1500VA/810W power-handling capacity supports entry-level PCs, home entertainment systems, network workstations and audio/video components.

• UPC Code: 037332173249
• UPS Type: Line-Interactive
• Input Phase: Single-Phase
• Rated input current (Maximum Load): 12A
• Nominal Input Voltage(s) Supported: 120V AC
• UPS Input Connection Type: 5-15P
• Input Circuit Breakers: 15A
• UPS Input Cord Length (ft.): 6
• Recommended Electrical Service: 15A 120V
• Output Capacity (VA): 1500
• Output Capacity (kVA): 1.5
• Output Capacity (Watts): 810
• Output Capacity (kW): 0.81
• Nominal Voltage Details: 120v nominal output in battery mode
• Frequency Compatibility: 50 / 60 Hz
• Frequency Compatibility Details: Automatic frequency selection
• Output Voltage Regulation (Line Mode): 120V (+9% / -12%)
• Output Voltage Regulation (Economy Line Mode): 120V (?10%)
• Output Voltage Regulation (Battery Mode): +/- 5%
• UPS Output Receptacles (Surge Suppression Only): 5 UPS outlets, 5 surge-only outlets
• Hot-Swap PDU options: PDUB15 (2U / 8 5-15R outlets)
• Output AC Waveform (AC Mode): Sine wave
• Output AC Waveform (Battery Mode): PWM sine wave
• Nominal Output Voltage(s) Supported: 110V; 115V; 120V
• Output Receptacles: (10) 5-15R
• Battery Type: Valve Regulated Lead Acid (VRLA)
• Runtime Full Load (min.): 1.8 min. (810W)
• Runtime Half Load (min.): 7.5 min. (405W)
• DC System Voltage (VDC): 24
• Battery Recharge Rate (Included Batteries): Less than 8 hours from 10% to 90%
• Internal UPS Replacement Battery Cartridge: RBC51 (requires 2)
• Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 92 to 150
• Overvoltage Correction: Input voltages between 129 and 147 are reduced by 15%
• Undervoltage Correction: Input voltages between 92 and 108 are boosted by 18%
• Front Panel LCD Display: LCD screen with scroll buttons indicates Input voltage, Output voltage, Frequency (Hz), AVR boost / cut status, Output load in watts, Output load percentage, Battery voltage and Estimated runtime in minutes
• Switches: Power switch offers whole UPS power control; Scroll/mute button enables LCD selection options and silences audible alarm; Test button initiates self test
• Alarm Cancel Operation: Power-fail alarm can be silenced using alarm-cancel switch
• Audible Alarm: Audible alarm indicates power-failure and low-battery conditions
• UPS AC Suppression Joule Rating: 650
• UPS AC Suppression Response Time: Instantaneous
• UPS Dataline Suppression: 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet; Coax jacks (1 set)
• EMI / RFI AC Noise Suppression: Yes
• Primary Form Factor: Tower
• Cooling Method: Fan
• Installation Form Factors Supported with Included Accessories: Tower
• Primary UPS Depth (mm): 396
• Primary UPS Height (mm): 203
• Primary UPS Width (mm): 146
• Shipping Dimensions (hwd / in.): 11.20 x 9.10 x 19.40
• Shipping Weight (lbs.): 25.10
• UPS Power Module Dimensions (hwd, in.): 8 x 5.75 x 15.6
• UPS Power Module Weight (kg): 11.52
• UPS Power Module Weight (lbs.): 25.4
• Unit Weight (lbs.): 22.700
• Operating Temperature Range: 32? to 104?F (0? to 40?C)
• Storage Temperature Range: 5? to 122?F (-15? to 50?C)
• Relative Humidity: 5 to 95%, non-condensing
• AC Mode BTU / Hr. (Full Load): 98
• Battery Mode BTU / Hr. (Full Load): 826
• AC Mode Efficiency Rating (100% Load): 95%
• PowerAlert Software: For local monitoring via the UPS's built-in USB port, download PowerAlert software at https://tripplite.eaton.com/products/power-alert
• Communications Cable: USB cabling included
• WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications
• Network UPS Tools (NUT) Compatibility: NUT compatible. See a full list of NUT compatible Tripp Lite UPS systems at https://networkupstools.org/stable-hcl.html?manufacturer=Tripp%20Lite
• Network Management Card Description: Network management not supported
• Communications Interface: USB (HID enabled)
• Transfer Time: 2 milliseconds (AC to battery mode), 6 milliseconds (battery to AC mode)
• Low Voltage Transfer to Battery Power (Setpoint): 92
• High Voltage Transfer to Battery Power (Setpoint): 150
• Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported
• High Availability UPS Features: Automatic Voltage Regulation (AVR); Surge/noise protection
• Green Energy-Saving Features: Greater than 95% efficiency - GREEN UPS
• UPS Applications: Home/Office Desktop; Audio/Video; High-End Desktop/Small Network; Retail/Point of Sale; Hospitality
• Product Certifications: CSA (Canada); NOM (Mexico); UL 1778
• Product Compliance: RoHS; ENERGY STAR Qualified; FCC Part 15 Class B (USA)
• Product Warranty Period (U.S. & Canada): 3-year limited warranty
• Connected Equipment Insurance (U.S., Canada & Puerto Rico): $250,000 Ultimate Lifetime Insurance
